The Most Cost-Effective Puffed Snack Food Extruder Making Machine Stainless Steel Frying Snacks Fully Automatic Fried French Chips Production Equipment

Product Description

The key and key technology of the SLG twin screw food production line is the use of extrusion technology, which is the most "popular" and "high-tech" food processing technology in the world today. After being expanded, grains become larger in volume, fluffy in tissue, gelatinized in starch, and have an increase in water-soluble components, which are easily digested and absorbed by the human body. Therefore, they are widely welcomed by consumers from various countries.

Our company's fried snack production line mainly has three types of hosts to choose from, and the output and size of different hosts vary. Enterprises can decide based on their own production needs.

Process flow of fried wheat flour snack production line: Mixer - Spiral extractor - Twin screw host - Traction cutting machine - Automatic fryer - Drum seasoning line

Main Functions of Production Line Equipment

1. Mixer: Mix the raw materials and a certain amount of water required for production thoroughly and evenly to form the necessary materials for production.
2. Spiral feeder: The mixed raw materials are transported to the feeding hopper of the extruder.
3. Twin screw host: High-temperature and high-pressure extrusion to form final shapes of snacks.
4. Traction cutting machine: Cutting semi-finished products uniformly.
5. Automatic fryer: Fry the product to ensure crisp texture.
6. Octagonal seasoning machine: Flavoring the fried products.

Multi Configuration Host Equipment Advantages

• Direct transmission motor and distribution box reduces energy loss
• Modular composite alloy screw for customization
• Automatic heating and cooling system for stable operation
• Frequency conversion speed control for smooth operation
• Double spiral forced feeding for consistent supply
• Suspended mold assembly and linear bearing knife adjustment
• Imported bearings for strong load-bearing
• Automatic lubrication ensures longevity

Introduction to Host Parameters

Model SLG65-C
Installed power: 40.75kW
Power consumption: 26kW
Capacity: 100-150kg/h
Dimension: 16500×2250×2900mm

Model SLG70-A
Installed power: 76.05kW
Power consumption: 54kW
Capacity: 250-300kg/h
Dimension: 20000×2250×2800mm

Model SLG85-A
Installed power: 121.05kW
Power consumption: 91kW
Capacity: 350-400kg/h
Dimension: 20800×3000×3000mm

Snacks Produced

It can produce fried wheat flour snack, Jiangmi strip, core-filling rolls and other direct puffed snacks. It can also produce nutritional powder, grain gruel and many other snacks by changing moulds and assistant equipments.
